Automatic Closed Cup Flash Point Tester

Additional information


SKU KRFL93A-0000 Category
Price :


Automatic Closed Cup Flash Point Tester is designed and made as ASTM D93 standard test method .This test method is for determination of petroleum products according to Pensky-Martens closed-cup apparatus.

Feature & Specification

Automatic Closed Cup Flash Point Tester

This test methods cover the determination of the flash point of petroleum products in the temperature range from 40 to 360°C by a manual Pensky-Martens closed-cup apparatus or an automated Pensky-Martens closed-cup apparatus, and the determination of the flash point of biodiesel in the temperature range of 60 to 190°C by an automated Pensky-Martens closed cup apparatus.

1. Highly automatic design, the apparatus automatically competes control,sweeping ignition, flash examination, alarming, result calculation and etc. it can complete all the experiment procedures with nobody watches.

2. The apparatus configures high precision needle-type valve to control gas resource, can precisely ensure testing flame ball as standard required.

3. All the gas source pipes are made of stainless steel, which made it safe and reliable.

4. The tester conforms to the A and B procedures of the standard requirement to truly realize two experiential methods tested in one apparatus.

5. There is a lighting ignition plug equipped on the flame ball, which ensures the fireball burns all along during the testing process, safe and reliable.

Specification :

1. Rated voltage: AC220V±10% 50HZ
2. Power: 700W
3. Operating model: LCD touched screen
4. Ignition ay: Automatic digital ignition
5. Cooling method: double enforcing fan cooling system
6. Printer: Thermo sensitive printer
7. Cooling way: Enforcing cooling by double fan
8. Detection way : Automatic
